Concrete Cooling Tower/ Water Tower

Prod Model:	NWI-2000
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Cooling Capacity:	2000ton
Frame Material:	C20 Concrete
Infill:	PVC,PP
Application:	Power Station, Chemical Plant, Sea Water Cooling
Cooling Method:	Counter Flow
Material:	Concrete
Certification:	Cti
Condition:	New

Product Description

Features:

Concrete frame and wall.
The type of cooling tower can working with seawater, power plant, nitrogenous fertilizer plant, which water quality is acidic and alkaline. Concrete tower with anticorrosion design can be used for cooling almost any type of chemical water. Tower budy is stong and long life.

Excellent Design and Long lifetime.
The shell of cooling tower adopts high quality and toughness glass fiber, beautiful shape, resistants to natural factors and chemical material erosion, looks brand new even after long time use. All the steel shelves are processed by immersive hot galvanized zinc and comply with British BSENISO1461: 1999 standard, reducing the oxidation mostly, prolong the service life.

High Efficiency and Energy Saving
Newin NWI series cooling tower using excellent quality PVC film as thermal interface material, corrosion resistant, no deformation, curved and diagonal design film effectively prolongs exchange time between high temperature water and air inside cooling tower, which makes air flow smoothly and resistance lower, meanwhile, making the water drift ratio lowest, furthermore, the axial and arc fan, specially designed basin with evenly distributed waterstoma, which highly improved heat exchange rate of cooling tower and lower the entire cooling tower's energy consumption and noise.

Easy Installation, Reasonable and Practical Usage
Newin NWI series cooling towers can be paralleled for multi-units, flexible combination, widely used. The body structure is tidy, standardized, compact and strong, which is easy for installation. The design and manufacture are all on basis of practical uses, so it can meet customers' requirement better with high quality.

Model	NTG	800	1000	1500	2000	2500	3000	3500	4000
Nominal flow	m 3 /h	800	1000	1500	2000	2500	3000	3500	4000
Cooling capacity	Kcal/h	8.0×10 6	1.0×10 7	1.5×10 7	2.0×10 7	2.5×10 7	3.0×10 7	3.5×10 7	4.0×10 7
Water pressure	×10 4 pa	8.0	8.8	10.0	11.0	11.5	12.0	13.3	13.5
Net weight	Ton	11.63	19.68	29.34	45.03	46.2	65.0	76.05	78.5
Running weight	Ton	18.45	31.23	46.75	68.69	75.3	99.2	104.8	132.0
Noise	dB(A)	71	72	72.5	73	73.5	73.5	74	74
Air volume	km 3 /h	600	900	1200	1750	2100	2400	2730	3150
Fan diameter	mm	4700	5460	6000	7700	8000	8530	9140	9140
Motor power	kW	30	45	55	90	132	160	160	200
Motor speed	rpm	220	165	165	149	149	149	110	110
Length	mm	7400	9000	10500	12000	13500	15000	16000	17400
Width	mm	7400	9000	10500	12000	13500	15000	16000	17400
Height	mm	7800	8700	9500	10200	10700	11400	12100	12400
Fan stack height	mm	2800	3100	3600	3800	4000	4200	4400	4400
Coaming height	mm	3500	3800	3800	4000	4000	4200	4500	4500
Air inlet height	mm	1500	1800	2100	2400	2700	3000	3200	3500
Water inlet height	mm	4000	4300	4600	4900	5200	5500	5700	6000
Water inlet diameter	mm	400	450	500	450*2	450*2	500*2	500*2	550*2
Fan stack	Fiberglass Reinforced Polyester
Exhaust fan	Completed equipment
Ladder	Galvanized steel
Roof plate	Fiberglass Reinforced Polyester / Gavanized steel
Water eliminator	PVC
Sprinkler system	Galvanized steel & P.V.C
Infill	PVC
Casing	Fiberglass Reinforced Polyester
Ice-melting pipe	Galvanized steel
Clapboard	Fiberglass Reinforced Polyester
Frame	Galvanized steel / Concrete
Pool	Concrete
