Gold Copper Tin Ore Mining Shaking Table
| Price: | US $ 1500/Set |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
Features
1. High recovery ratio
2. High concentration ratio
3. Easy installation
4. Simple operation
5. Deck constructed of fiber glass
6. Three different decks to choose
7. Long working life
8. Adjustable stroke length and speed
Shaking Table
Which is also called table concentrator, is a mine separation device for fine minerals working by gravity. They are effective in processing precious and base metal, rare metal and non-metallic minerals, widely used in separation for Gold, Silver, Tin, Columbium, Tantalum, Titanium, Barium, Tungsten, Iron, Chrome, Manganese, Zircon, Lead, Zinc, Mercury, Copper, Aluminum, etc.
For the shaking table:
1. Frame beam square tube is 2.5mm, other factories are 1.5-2mm;
2. Retaining dam steel plate's thickness is 4mm, other factories are 2-3mm;
3. Glass fiber reinforced plastics is thicker than other factories;
4. Each table deck is 60kg heavier than other factories;
5. We use Premium Brand Motor which is pure copper, other factories use the ordinary electric machine with aluminium winding.
Construction and mechanical features
Head Motion Gandong shaking tables are furnished with a totally enclosed self-oiling head motion of heavy cast iron to contain an oil reservoir for perfect splash lubrication. This feature protects the moving parts, reducing operating and maintenance costs to a minimum.
Decks The decks are constructed of steel framework and covered 16mm fibreglass with corundum, this cover its strength reaches as high as 70% of steel, the features of this design are stronger, wear-resistant,
Corrosion-resistant, and no distortion, it lengthens the working-life of machine and thus allows machine perform perfectly on different mineral and different weather condition.
We are professio
Now our products have been exported to over 57 countries, such as USA, England, Australia, Brazil, Turkey, Italy, Russia, SouthAfrica, Zimbabwe, Sudan, Ghana, Congo, Morocco, India, Indonesia, Malaysia, Philippines, NorthKorea, Mongolia, Vietnam, Thailand etc.
Our faith: Customer is the god.
Our goal is to provide customers with one-stop service in the field of mining, including the minerals in the mineral analysis, mineral processing test, engineering design, equipment production, equipment installation, equipment debugging and of technical training etc integrated services, through the provision of our perfect services to solve all customer's problem from his investment to his return.
Mobile: +86 182 9677 5735
Website: www.benefication.com
1. High recovery ratio
2. High concentration ratio
3. Easy installation
4. Simple operation
5. Deck constructed of fiber glass
6. Three different decks to choose
7. Long working life
8. Adjustable stroke length and speed
Shaking Table
Which is also called table concentrator, is a mine separation device for fine minerals working by gravity. They are effective in processing precious and base metal, rare metal and non-metallic minerals, widely used in separation for Gold, Silver, Tin, Columbium, Tantalum, Titanium, Barium, Tungsten, Iron, Chrome, Manganese, Zircon, Lead, Zinc, Mercury, Copper, Aluminum, etc.
For the shaking table:
1. Frame beam square tube is 2.5mm, other factories are 1.5-2mm;
2. Retaining dam steel plate's thickness is 4mm, other factories are 2-3mm;
3. Glass fiber reinforced plastics is thicker than other factories;
4. Each table deck is 60kg heavier than other factories;
5. We use Premium Brand Motor which is pure copper, other factories use the ordinary electric machine with aluminium winding.
Construction and mechanical features
Head Motion Gandong shaking tables are furnished with a totally enclosed self-oiling head motion of heavy cast iron to contain an oil reservoir for perfect splash lubrication. This feature protects the moving parts, reducing operating and maintenance costs to a minimum.
Decks The decks are constructed of steel framework and covered 16mm fibreglass with corundum, this cover its strength reaches as high as 70% of steel, the features of this design are stronger, wear-resistant,
Corrosion-resistant, and no distortion, it lengthens the working-life of machine and thus allows machine perform perfectly on different mineral and different weather condition.
We are professio
nal beneficiation and separating machine manufacturer. Can supply all kind of mining equipments, like Trommel, Sluice, Hopper, Conveyor, Rolling Sieve, Shaking Sieve, Centrifugal Concentrator, Jigging sluice, Gold carpet, etc... Welcome to contact us for more details.Provide equipments diagram and equipment layout etc.......
We can make a special mineral processing approach for you with least cost & simplest way.
We can provide the most suitable whole set equipments for your ore.
We can provide you the best price & the best service.We also provide all small/lab testing mining equipment, welcome to contact me for the details
Now our products have been exported to over 57 countries, such as USA, England, Australia, Brazil, Turkey, Italy, Russia, SouthAfrica, Zimbabwe, Sudan, Ghana, Congo, Morocco, India, Indonesia, Malaysia, Philippines, NorthKorea, Mongolia, Vietnam, Thailand etc.
Our faith: Customer is the god.
Our goal is to provide customers with one-stop service in the field of mining, including the minerals in the mineral analysis, mineral processing test, engineering design, equipment production, equipment installation, equipment debugging and of technical training etc integrated services, through the provision of our perfect services to solve all customer's problem from his investment to his return.
Mobile: +86 182 9677 5735
Website: www.benefication.com
| Model | 6-S 7.6 | 6-S 4.08 | 6-S 1.95 | 6-S 0.5 | ||||
| Deck type | Course ore Deck | Fine sand Deck | Slime Deck | Three different kinds of decks are available | ||||
| Beneficiation Area (m 2 ) | 7.6 | 7.6 | 7.6 | 4.08 | 1.95 | 0.5 | ||
| Deck Size | Length (mm) | 4450 | 4450 | 4450 | 3000 | 2100 | 1100 | |
| transmission end width (mm) | 1855 | 1855 | 1855 | 1320 | 1050 | 500 | ||
| Concentrate end width (mm) | 1546 | 1546 | 1546 | 1100 | 850 | 430 | ||
| Maximum Feeding Size (mm) | 2 | 0.5 | 0.15 | Sand -2 Slime -0.1 | Sand -2 Slime -0.074 | Sand -2 Slime -0.074 | ||
| Feeding Amount | 30-60 T/d | 10-20 T/D | 15-25 T/D | 0.4-1.5 T/h | 0.3-0.8 T/h | 0.05-0.2 T/h | ||
| Feeding Density (%) | 25-30 | 20-25 | 15-25 | 10-30 | ||||
| Stroke (mm) | 16-22 | 11-16 | 8-16 | 6-30 | 12-28 | 9-17 | ||
| Frequency (F) | 45-48 | 18-53 | 50-57 | 210-320 | 250-450 | 280-460 | ||
| Water added | 80-150 T/d | 30-60 T/d | 10-17 T/d | 0.3-1.5 T/h | 0.2-1 T/h | 0.1-0.5 T/h | ||
| Transverse slope of Deck | 2°30-4°30 | 1°30-3°30 | 1°-2° | 0-10° | 0-8° | 0-10° | ||
| Longitudinal slope of Deck | 1.4 | 0.92 | ------ | ------ | ------ | ------ | ||
| Cross-section Shape of Deck | Rectangular | Saw-tooth | Triangle | AvailableRectangular, Saw-tooth, Triangle | ||||
| Motor Power (Kw) | 1.1 | 1.1 | 1.1 | 1.1 | 1.1 | 0.55 | ||
| Transmission Mechanism | Eccentric linkage | |||||||
| Prod Model: | 6-S 7.6 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Service: | Engineers Available to Service Machinery Overseas |
| Model: | 6-S |
| Deck Type: | Three Different Kinds of Decks Are Available |
| Beneficiation Area (M2): | 7.6 |
| Capacity (T/H): | 1-1.8 |
| Feeding Density (%): | 20-30 |
| Stroke (Mm): | 16-22 |
| Frequency Of Stroke (R/Min): | 220 |
| Water Consumption (T/H): | 0.7-1 |
| Groove Shape Of Deck: | Available Rectangular, Saw-Tooth, Triangle |
| Type: | Gravity Separator |
| Voltage: | 380V |
| Weight: | 1T |
| Certification: | CE |
| Warranty: | 2 Years |
| Color: | Multi Color |
| Customized: | Customized |
| Condition: | New |
| Material Feature: | Fiber Glass |
