Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 5/Piece |
Pay Type: | L/C,T/T,Western Union,Paypal |
Metal thickness | 0.8 to 1.5mm |
Type of Metal | SPCC Cold Rolled Steel |
Paint type and thickness | Thermosetting plastic powder, 0.17 to 0.3mm |
Castor diameter | 3 inches Castor total height 105mm, wheel diameter 105mm. Mounting holes distance: 73 * 44.5mm Material: steel and rubber The material strength of steel and rubber is 235MPa. The castor heavy duty is 600-800KG |
Total dimension of the cabinet (Without castors) Total dimension of the cabinet (With castors) | 700(W)X600(D)X1021(H) 700(W)X600(D)X1126(H) |
Shelf dimension | 603(W)X350(D)X26.5(H) |
5 ways PDU | 1.5U 5ways South African type PDU, with 1P circuit breaker, power cord 3G1.5mm2 520mm, IEC C20 plug.(L×W×H=429.6×62×45mm) |
15 ways PDU | 1.5U 15ways South African type PDU, with 1P circuit breaker, power cord 3G1.5mm2 470mm, IEC C20 plug.(L×W×H=981.1×62×45mm) |
External power supply | 1×C20 module |
Internal power supply | 3×C19 module |
Specification of mounting rails and vertical cable manager | NO Mounting Rails |
Specification of vertical cable manager | 94(W)X760(H)X66(D) |
Specification of handle lock | 142*32*42 |
Specification of small round lock | Φ22*20 |
Specification of side bars | Dia. 25mmMounting hole center distance 440mm |
Prod Model: | TN-LCC001 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Capacity For Laptops: | 20PCS/Optional |
Color: | Red, Orange, Blue, Black |
Transportation: | Truck, Sea, Air. |
Logo: | Sticker. Silk Print |
Type: | Network Cabinet |
Usage: | Network Integration System |
Installation: | Vertical |
Fan Number: | Two |
Certification: | RoHS |
Condition: | New |
