Plastic Speake Cabinet (PS15DA)
| Price: | US $ 230/Piece |
|---|---|
| Trade Terms: | others |
| Min Order: | 2/Piece |
| Pay Type: | T/T,Paypal,Western Union |
Plastic Speaker Cabinet PS15DA
Features
Compression driver with 1inch Titanium Dome
15inch power woofer with 65mm voice coil.
130dB Max SPL.
Light-weight and high-power output.
Applications
Live performance sound reinforcement.
Thearters, theme park, houses of workshop.
Stage monitor.
Features
Compression driver with 1inch Titanium Dome
15inch power woofer with 65mm voice coil.
130dB Max SPL.
Light-weight and high-power output.
Applications
Live performance sound reinforcement.
Thearters, theme park, houses of workshop.
Stage monitor.
| System Type: | 15inch two-way passive speaker. |
| Frequency Response: | 65Hz--18 kHz ± 3dB |
| Sensitivity (1W/1M): | 96dB. |
| Impedance: | 8ohm |
| Rated Power: | 350W (AES), 700W (PEAK). |
| Dispersion: | 90° (H) X 60° (V) |
| Drivers: | LF driver 15' ' transducer (65mm) voice coil |
| HF driver 1' ' exit (44mm) voice coil. | |
| Maximum SPL: | 130dB peak. |
| Connectors: | XLR - JACK/XLR. |
| Dimensions: | (W) 460mm x (H) 710mm x (D) 406mm |
| Weight: | 19.2kg |
| Prod Model: | PS15DA |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| System Type: | 15inch, 2-Way Speaker |
| Frequency Response: | 65Hz -- 18kHz |
| Dispersion (Hxv): | 90 X 60 |
| Handling Power: | 350watts (RMS) / 700watts (Peak) |
| Noise: | <95dB |
| Application: | Commercial |
| Certification: | CCC |
| THD: | <0.03% |
