Dachang Hui Autonomous County Xiadian Jiamei Sporting Goods Co., Ltd. >> Sporting Goods -Outdoor Table Tennis Table-06-313xo
Sporting Goods -Outdoor Table Tennis Table-06-313xo
| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
Product Descirption
06-313 Outdoor fitness equipment table tennis table
Details
We are a professional table tennis tabls manufacturer. Built powerfully for permanent installation
Outdoors. Endures the most inclimate weather. This system is fully tested over decades as it is installed in thousand of community parks throughout China, where table tennis is the nation's most popular sport. Table Tennis promotes agility, speed and hand, eye, ball coordination. It can be practiced by people of all ages.
1. Table net is made of whole iron plate and the thickness is 1.80mm
2. Two stainless steel screws and nuts and stainless steel anti-theft caps to do a double
guarantee
3. Iron ball with 1kg freely falls from 1000mm high to table-board for times, there is no any
changes on the table-board, it is not easy to fade
4. Anti-theft screw to fix the table-board onto iron frame and prevent it from stealing
5. Thickness of iron frame is 2.00mm
6. Thickness of "Rainbow" stand is 2.75mm
7. Service life 8 years
Dimension(L×W×H): 2740×1525×760mm
Main material: Steel pipe,SMC
Main Column Size: 48mm×2.75mm
Main Supporting Pipe Size:20mm×30mm×2mm
Surface Treatment Technology: Degreasing - Sand Blasting
- Electrostatic Spraying
Installation:Main: Pre- Buried
FAQ
1. Payment Terms ?
50% as deposit by T/T and the rest will be paid before shipment.
L/C.
2. Container Loading Qty ?
50 sets per 20GP, 100 sets per 40HQ.
3. Quality Guarantee Time ?
1 year.
4.Double powder?
First powder is epoxy powder, second powder is regular color powder same as pictures. Powder are bulk purchased from Nippon, Dupont, Aksu.
06-313 Outdoor fitness equipment table tennis table
Details
We are a professional table tennis tabls manufacturer. Built powerfully for permanent installation
Outdoors. Endures the most inclimate weather. This system is fully tested over decades as it is installed in thousand of community parks throughout China, where table tennis is the nation's most popular sport. Table Tennis promotes agility, speed and hand, eye, ball coordination. It can be practiced by people of all ages.
1. Table net is made of whole iron plate and the thickness is 1.80mm
2. Two stainless steel screws and nuts and stainless steel anti-theft caps to do a double
guarantee
3. Iron ball with 1kg freely falls from 1000mm high to table-board for times, there is no any
changes on the table-board, it is not easy to fade
4. Anti-theft screw to fix the table-board onto iron frame and prevent it from stealing
5. Thickness of iron frame is 2.00mm
6. Thickness of "Rainbow" stand is 2.75mm
7. Service life 8 years
Dimension(L×W×H): 2740×1525×760mm
Main material: Steel pipe,SMC
Main Column Size: 48mm×2.75mm
Main Supporting Pipe Size:20mm×30mm×2mm
Surface Treatment Technology: Degreasing - Sand Blasting
- Electrostatic Spraying
Installation:Main: Pre- Buried
FAQ
1. Payment Terms ?
50% as deposit by T/T and the rest will be paid before shipment.
L/C.
2. Container Loading Qty ?
50 sets per 20GP, 100 sets per 40HQ.
3. Quality Guarantee Time ?
1 year.
4.Double powder?
First powder is epoxy powder, second powder is regular color powder same as pictures. Powder are bulk purchased from Nippon, Dupont, Aksu.
1) Are you a manufacturer?
Yes, Xiadian Jiamei Sporting Goods Company has been in the field of fitness equipment for more than 12 years, we are one of the three "Outdoor Fitness Equipment Demonstration Enterprise" in China with mature management, advanced production experience, high-tech production machine. You are warmly welcomed to visit the fitness equipment manufacture base as big as 67000m2.
2) What certficates do you have
We are manufacturer with ISO9001, ISO14001, ISO18001
Also the fitness equipment possess NSCC, TUV certificates
3) What is the production time?
Normally the production time is 25days when the purchase items in a certain scale. You are welcomed to send the draft order to get the best producton time.
| Prod Model: | 06-313XO |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Package: | Carton |
| Type: | Table Tennis Table |
| Bat Type: | Plastic Sponge Bat |
| Table Type: | Non Rolling Table |
| Star Level: | Two Star |
| Handle Style: | Penhold Short Handle |
| Usage: | for Conventional Game |
| Suitable For: | Stadium |
| Table Color: | Silver |
| Color: | Red |
| Brand: | Jiamei |
Xiadian Jiamei Sporting Goods Co., Ltd. is a professional manufacturer specializing in outdoor fitness equipment, table tennis table, basketball stand and other sporting goods. We have hundreds of SPORTING PRODUCTS (sporting products): RECOVERY FITNESS EQUIPMENT(recovery fitness equipment), LANDSCAPE FITNESS EQUIPMENT WITH UMBRELLA (landscape fitness equipment with umbrella), PARK FITNESS EQUIPMENT (park fitness equipment), BASKETBALL STAND(basketball stand), TABLE TENNIS TABLE(table tennis table), CHILDREN PALYGROUND(children playground), SCHOOL FITNESS EQUIPMENT(school fitness equipment), PARK FITNESS EQUIPMENT(park fitness equipment) etc. They are widely stationed in parks, squares, schools, universities, communities, resorts, private homes, medical facilities and more.
Advantage of Jiamei
First. ADVANTAGE OF QUALIFICATION
A. China Outdoor Fitness Alliance Vice President Compamy;
B. The member of China Sporting Goods League;
C. China Stationery and Sporting Goods Association.
2. Germany GS Safety Certificate
Certificates: Authentication Certificate of Quality Management System Authentication Certificate of Environmental Management System Authentication Certificate of Occupational Health and Safety Management System
3. All of products have passed the inspection by China Sporting Goods Quality Test Center and all of them are insured by Chinese Pacific Ocean Property Insurance Co., Ltd.
Second. ADVANTAGE OF TECHNOLOGICAL EQUIPMENT
1. Adopting CO2 protected welding, the surface is more beautiful and its intensity is higher than other ordinary welding.
2. The first company introducing sand blasting to remove rust in the area of Sporting Goods. Sand blasting adopts physical derusting which is environmental protection and enlarges the surface area of pipe.
3. Powder coating production line. Unique preheat device can ensure the capacity of powder adsorption, as long as more than 70-meters heat retaining district makes power solidify fully, releasing the remained water vapor and welding gas of welding area to ensure the powder coating quality.
4. Advanced facilities: CO2 protection welding machine, Plasma cutting machine, Curing machine, Punching machine, Radial drilling machine, Table drill press, Spray powder production line, Hydraulic bearing assembly machine etc.
Third. ADVANTAGE OF TECHNOLOGY
1. Execute according to GB19272-2011 General Requirements of Fitness Equipment strictly, but the design exceeds Chinese National Standard.
2. Complete Detection equipment. Power-driven Brinell Hardness Gauge, Xenon Weather-Ometer, Temperature Chamber, Microprocessor Control Universal Tester, Salt Spray Tester, Height Gauge 0-500, Vernier Caliper, Fatigue Test Machine, Impact Tester for Air Walker, Thickness Gauge etc.
3. Skilled staff: In the factory, 10 Senior technical staff, 18 middle class technical staff. Weekly technical training system and monthly technical ensure technical level of staff a sustaining improvement.
Fourth. ADVANTAGE OF QUALITY
1. Raw material and Auxiliary material: Adopting steel tube, iron plate, molding powder, welding wire made from companies with full qualification and reputation in domestic.
2. Important specification of raw material will be checked regularly, for example:
3. Insist the system of quality sustaining.
4. Every process are controlled according to process instruction written by professional technologist, it avoids arbitrary and non controllable with the production, builds quality control system of workpiece with traceability.
Fifth. ADVANTAGES OF PRODUCTION CAPACITY
Our company is a large Chinese production base of sports equipment, covering an area of more than 40 acres. Monthly production capacity is more than 4000 pieces of fitness equipment, the strong production capacity ensures the capacity of promptly supply.
Sixth. MARKETING ADVANTAGES
Xiadian Jiamei Imp&Exp Co., Ltd., the wholly-owned subsidiaries was established to develop international market.
Advantage of Jiamei
First. ADVANTAGE OF QUALIFICATION
A. China Outdoor Fitness Alliance Vice President Compamy;
B. The member of China Sporting Goods League;
C. China Stationery and Sporting Goods Association.
2. Germany GS Safety Certificate
Certificates: Authentication Certificate of Quality Management System Authentication Certificate of Environmental Management System Authentication Certificate of Occupational Health and Safety Management System
3. All of products have passed the inspection by China Sporting Goods Quality Test Center and all of them are insured by Chinese Pacific Ocean Property Insurance Co., Ltd.
Second. ADVANTAGE OF TECHNOLOGICAL EQUIPMENT
1. Adopting CO2 protected welding, the surface is more beautiful and its intensity is higher than other ordinary welding.
2. The first company introducing sand blasting to remove rust in the area of Sporting Goods. Sand blasting adopts physical derusting which is environmental protection and enlarges the surface area of pipe.
3. Powder coating production line. Unique preheat device can ensure the capacity of powder adsorption, as long as more than 70-meters heat retaining district makes power solidify fully, releasing the remained water vapor and welding gas of welding area to ensure the powder coating quality.
4. Advanced facilities: CO2 protection welding machine, Plasma cutting machine, Curing machine, Punching machine, Radial drilling machine, Table drill press, Spray powder production line, Hydraulic bearing assembly machine etc.
Third. ADVANTAGE OF TECHNOLOGY
1. Execute according to GB19272-2011 General Requirements of Fitness Equipment strictly, but the design exceeds Chinese National Standard.
2. Complete Detection equipment. Power-driven Brinell Hardness Gauge, Xenon Weather-Ometer, Temperature Chamber, Microprocessor Control Universal Tester, Salt Spray Tester, Height Gauge 0-500, Vernier Caliper, Fatigue Test Machine, Impact Tester for Air Walker, Thickness Gauge etc.
3. Skilled staff: In the factory, 10 Senior technical staff, 18 middle class technical staff. Weekly technical training system and monthly technical ensure technical level of staff a sustaining improvement.
Fourth. ADVANTAGE OF QUALITY
1. Raw material and Auxiliary material: Adopting steel tube, iron plate, molding powder, welding wire made from companies with full qualification and reputation in domestic.
2. Important specification of raw material will be checked regularly, for example:
3. Insist the system of quality sustaining.
4. Every process are controlled according to process instruction written by professional technologist, it avoids arbitrary and non controllable with the production, builds quality control system of workpiece with traceability.
Fifth. ADVANTAGES OF PRODUCTION CAPACITY
Our company is a large Chinese production base of sports equipment, covering an area of more than 40 acres. Monthly production capacity is more than 4000 pieces of fitness equipment, the strong production capacity ensures the capacity of promptly supply.
Sixth. MARKETING ADVANTAGES
Xiadian Jiamei Imp&Exp Co., Ltd., the wholly-owned subsidiaries was established to develop international market.
