Nanjing Ebil Metal Products Co., Ltd. >> Storage Wire Decking Mesh Shelf (EBIL-WP)
Storage Wire Decking Mesh Shelf (EBIL-WP)
| Price: | US $ 1.22/Ton |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 20/Ton |
| Pay Type: | L/C,T/T |
Storage Wire Decking Mesh Shelf
A) Galvanized finish or powder coated finish
B) 1.5" waterfall front and rear
C) Build products to your specifications
D) 500-5, 000 lbs load capacity
E) Allows free passage of water, so overhead sprinklers operate effectively
F) Qualifies for reduction in fire insurance premiums
G) Stays cleaner because dirt cannot build up on wire grid
H) Lighter in weight and easy to handle
I) Will not rot or splinter and have no nails
A) Galvanized finish or powder coated finish
B) 1.5" waterfall front and rear
C) Build products to your specifications
D) 500-5, 000 lbs load capacity
E) Allows free passage of water, so overhead sprinklers operate effectively
F) Qualifies for reduction in fire insurance premiums
G) Stays cleaner because dirt cannot build up on wire grid
H) Lighter in weight and easy to handle
I) Will not rot or splinter and have no nails
WIRE DECKING | ||||||||||
| ITEMS | inch (D*W) | 50*100*Ø 5.5mm | Unit price | 50*100*Ø 6.0mm | Unit price | CONTAINER | ||||
| Load: 3500LBS | kg | LBS | USD | KG | LBS | USD | 20ft | 40ft | ||
| 1 | EBIL42-4-35 | 42" *35" | 11.85 | 26.1 | 13.03 | 13 | 28.6 | 14.30 | 900 | 1950 |
| 2 | EBIL42-5-48 | 42" *48" | 15.2 | 33.5 | 16.66 | 16.7 | 36.8 | 18.37 | 750 | 1450 |
| 3 | EBIL48-4-35 | 48" *35" | 13.4 | 29.5 | 14.74 | 14.7 | 32.4 | 16.17 | 700 | 1450 |
| 4 | EBIL48-5-48 | 48" *48" | 17.2 | 37.9 | 18.91 | 18.9 | 43.0 | 20.82 | 550 | 1100 |
| 5 | EBIL24-3-35 | 24" *35" | 7.0 | 15.5 | 7.65 | 7.7 | 17.0 | 8.47 | 1400 | 3000 |
| 6 | EBIL24-3-48 | 24" *48" | 8.2 | 18.1 | 9.03 | 9.2 | 20.3 | 10.12 | 1100 | 2100 |
| 7 | EBIL30-3-48 | 30" *48" | 9.7 | 21.4 | 10.71 | 10.9 | 24.0 | 11.99 | 750 | 1500 |
| 8 | EBIL36-3-35 | 36" *35" | 9.5 | 21.0 | 10.43 | 10.5 | 23.1 | 11.55 | 900 | 2100 |
| 9 | EBIL36-3-48 | 36" *48" | 11.3 | 24.9 | 12.47 | 12.7 | 28.0 | 13.97 | 700 | 1400 |
| 10 | EBIL42-4-35 | 42" *35" | 11.8 | 26.0 | 13.02 | 13.0 | 28.6 | 14.30 | 880 | 2100 |
| 11 | EBIL42-5-48 | 42" *48" | 15.0 | 33.0 | 16.50 | 16.7 | 36.8 | 18.37 | 700 | 1580 |
| 12 | EBIL48-4-35 | 48" *35" | 13.4 | 29.5 | 14.74 | 14.7 | 32.4 | 16.17 | 700 | 1580 |
| 13 | EBIL60-5-35 | 60" *35" | 24.7 | 54.4 | 27.21 | 500 | 900 | |||
| 14 | EBIL60-5-48 | 60" *48" | 28.6 | 63.0 | 31.42 | 400 | 750 | |||
| ITEMS | inch(D*W) | 63*114*Ø 5.5mm | Unit price | 63*114*Ø 6.0mm | Unit price | CONTAINER | ||||
| Load: 1500LBS | kg | LBS | USD | KG | LBS | USD | 20ft | 40ft | ||
| 15 | EBIL36-3-46 | 36" *46" | 10.2 | 22.5 | 11.22 | 12.2 | 26.9 | 13.42 | 900 | 1800 |
| 16 | EBIL36-3-52 | 36" *52" | 10.8 | 23.8 | 11.88 | 12.9 | 28.4 | 14.19 | 700 | 1400 |
| 17 | EBIL42-3-46 | 42" *46" | 11.8 | 26 | 12.98 | 13.1 | 28.9 | 14.41 | 950 | 1800 |
| 18 | EBIL42-3-52 | 42" *52" | 12.5 | 27.5 | 13.75 | 13.9 | 30.6 | 15.29 | 700 | 1400 |
| 19 | EBIL44-3-46 | 44" *46" | 12.2 | 26.9 | 13.42 | 13.4 | 29.5 | 14.74 | 800 | 1600 |
| 20 | EBIL44-3-52 | 44" *52" | 12.9 | 28.4 | 14.19 | 14.3 | 31.5 | 15.73 | 650 | 1300 |
| 21 | EBIL48-3-46 | 48" *46" | 13.2 | 29.1 | 14.52 | 14.5 | 31.9 | 15.95 | 800 | 1600 |
| 22 | EBIL48-3-52 | 48" *52" | 13.9 | 30.6 | 15.29 | 15.5 | 34.2 | 17.05 | 500 | 1000 |
| 23 | EBIL36-4-58 | 36" *58" | 12.9 | 28.4 | 14.19 | 14.2 | 31.3 | 15.62 | 700 | 1400 |
| 24 | EBIL42-4-58 | 42" *58" | 14.7 | 32.4 | 16.17 | 16.2 | 35.7 | 17.82 | 650 | 1300 |
| 25 | EBIL48-4-58 | 48" *52" | 16.7 | 36.8 | 18.37 | 18.5 | 40.8 | 20.34 | 460 | 1000 |
| Prod Model: | EBIL-WP |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: | as Request |
| Certificate: | CE |
| Capacity: | 1001kg-5000kg |
| Material: | Steel |
| Style: | Single Face |
| Entry Type: | 4-Way |
| Type: | Shelf Storage Cage |
| Mesh Spacing: | 50mm?รก50mm |
| Wire Diameter: | 5mm |
| Feet Height: | 120mm |
| Size: | as Request |
| Load Capacity: | Max 2000kg Per Layer |
| Wire Diameter: | Customed |
Ebil Metal(Nanjing) Products Co., Ltd, professional manufacturer of metal shelving, storage teardrop pallet rack system and Intelligent Manufacturing storage equipment. Has more than 26 years manufacturing experiences, 15years exporting experience, exported more than 120 countries, and finished more than 10000 rack projects from design, produce to install. Like Southeast Asia, Europe, and America etc., providing the timely, thoughtful, professional service to the growing customers to win and lasting trust and industry credibility from all of these customers.
For new and old import & export customers supply:
1. Solutions simple /regular warehouse rack/storage metal shelving, high-end warehouse / complete large-scale Intelligent Storage logistics system(6000MT/PER MONTH) warehouse planning, conveyance equipment; Various racking and storage management.; Optimize your warhouse; Economize space and cost.
2. A professional team, experienced engineers, advanced manufacturing equipment, particular production technology; Ebilmetal strictly implements ISO9001 Standard in all peration; Pass SGS and CE quality-guarantee system keep and assure customer products quality and delivery time.
3. Supply Specialized installation guidance and after services that anytime and any country if customer need
4. Reply your inquiries within 24 hours anytime and anywhere
Intelligent Manufacturing, Exclusive Customized
Create value services for the clients who approval our brand
For new and old import & export customers supply:
1. Solutions simple /regular warehouse rack/storage metal shelving, high-end warehouse / complete large-scale Intelligent Storage logistics system(6000MT/PER MONTH) warehouse planning, conveyance equipment; Various racking and storage management.; Optimize your warhouse; Economize space and cost.
2. A professional team, experienced engineers, advanced manufacturing equipment, particular production technology; Ebilmetal strictly implements ISO9001 Standard in all peration; Pass SGS and CE quality-guarantee system keep and assure customer products quality and delivery time.
3. Supply Specialized installation guidance and after services that anytime and any country if customer need
4. Reply your inquiries within 24 hours anytime and anywhere
Intelligent Manufacturing, Exclusive Customized
Create value services for the clients who approval our brand
