Class II Biological Safety Cabinet for Doing Dangerous Experiments

Name: Class II Biological Safety Cabinet for Doing Dangerous Experiments
Brand: thisfurniture.com
SKU: 697511882
Availability: InStock
Rating: 4.5 (103 reviews)

Price:	US $ 4100/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BSC-1800IIB2-X
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
External Size:	19508502200
Inflow Velocity/ Down Flow:	0.53 M/S;0.33 M/S
Weight:	420kg
Internal Size(mm):	1800600660

Product Description

Class II Biological Safety Cabinet
The Class II biological safety cabinet is an open-front, ventilated cabinet with negative pressure inside. The Class II biological safety cabinet will provide personnel, environment and product protection.It's always used for doing dangerous experiments or infective experiments.
Main Advantages
1,Remote Control
All functions can be realized through it, the first choice for preventing cross contamination.Much Easy and Safe to control and operation the cabinet.
2,Foot Switch
You can use foot switch to adjust the height of the front window during the test,which is much convenient.It's our unique design.
3,Four Sides Air Course Design
The four side air course designing makes the work area all around surrounded by negative pressure.
4,Timer Reserve Function
Mush useful and safety function,such as the starting timer,the UV sterilization timer,etc.
5,Various Display Screen
Using VFD,LED,LCD digital displaying for various models according to different customers' needed.
6,Filter & UV Life Attention
It can be showed in our VFD display.
7,Safety Power Lock and Cabinet Lock
To make sure nobody else can use the cabinet without allow.
8,Motor Controlled Laminated Glass
Much safety once broken and better effect to prevent the UV light.
9,Audio and Visual Alarm Function (Filter replacement,window over height,air flow abnormal etc.)
10,Interlock Function:UV Lamp and front window,UV lamp and blower,fluorescent lamp,Blower and front window.

According to the performance criteria
1  US Standard  ANSI/NSF49:2002
2  European Standard  EN12469:2000
3  Chinese Standard  YY0569-2005
Parameters for Class II A2 Biological Safety Cabinet

Main Parameters of Class II A2-X

Model	BSC-1100IIA2-X	BSC-1300IIA2-X	BSC-1500IIA2-X	BSC-1800IIA2-X	BSC-2000IIA2-X
Internal size(mm)	900600660	1100600660	1300600660	1600600660	1800600660
External size(mm)	11008502200	13008502200	15008502230	18008502300	19508502200
Tested Opening	Safety Height:≤200 mm
Max Opening	400mm
Inflow Velocity/ Down Flow	0.53 m/s;0.33 m/s
Filter	Two HEPA filter,99.999% efficient(0.3 microns)
Front Window	Two-layer toughened glass? >5mm
Noise	≤60 dB
UV lamp	18W×1	18W×1	30W×1	40W×1	40wX11
Fluorescent Lamp	21W×2	21W×2	28W×2	28W×2	40WX2
Lighting (Lux)	≥1000	≥1000	≥1000	≥1000	≥1000
Power(W)	760	1060	1300	1350	1700
Water and Gas Tap	Water Tap:1;Gas Tap:1.(Optional)
Waterproof Socket	Two,total consumption:500w
Display	LCD display
Control System	Microprocessor
Airflow System:	70% air recirculation,30% air exhaust
Material	Work zone interior is made of 304 stainless steel, Body: Epoxy coated cold rolled steel
Standard Base	635mm height
Caster Wheel	Universal wheel with brake and leveling feet
Electrical Parameter	110~240V/50~60Hz (optional)
Net weight(kg)	240	270	310	350	380
Gross weight(kg)	255	305	350	390	420
Package (mm)	125010501870	145010501870	164010451860	194010501960	209010501860
Standard Sets	Remote control, Foot switch, UV lamp*2,Fluorescent Lamp,Base Stand,Drain valve ,Waterproof Sockets
Optional Accessory	Armrest, Air curtain tester, Formalin fumigation sterilizer, Ammonium hydrogen carbonate, neutralizer,Infrared Sterilizer

Main Parameters of Class II B2-X

Model	BSC-1100II B2-X	BSC-1300II B2-X	BSC-1500II B2-X	BSC-1800IIB2-X
Internal size(mm)/ WDH	940×600×660	1100×600×660	1350×600×620	1600670630
External size(mm) WDH	1100×750×2250	1300×850×2200	1500×760×2250	18008402275
Tested Opening	Safety≤200 mm
Max Opening	400mm
Air Flow Velocity	Inflow:0.53m/s ± 0.025m/s;Down Flow Velocity:0.33 m/s ± 0.025m/s
Filter	Pre-filter:Washable,Two HEPA main filter:99.999% efficient(0.3 microns)
Front Window	Motorized,two layer laminated toughened glass
Noise	≤62dB
UV lamp	20W×1	20W×1		30W×1	40W×1
Fluorescent Lamp	21W×1	21W×1		28W×1	35W×2
Lighting	>=1000Lux	>=1000Lux		>=1000Lux	>=1000Lux
Power	1050W	1350W		1550W	1900W
Tap	Water Tap:1 ;Gas Tap: 1 (Optional)
Socket	Two,Waterproof,total consumption:500w
Display	LCD display
Control System	Microprocessor
Airflow System:	0 air recirculation,100% air exhaust
Exhaust Duct	4meters PVC duct,diameter: 300mm
Material	Work zone interior is made of 304 stainless steel Body:cold rolled steel with anti-bacteria powder
Base Height	635 mm
Caster Wheel	Universal wheel with brake and leveling feet
Electrical	110~240V/50~60Hz (optional)
N.W.	275kgs		320kgs	350kgs		390kgs
G.W.	350kgs		360kgs	440kgs		470kgs
Main Body Package/mm	125010501870		145010501870	164010451860		194010501860
Exhaust Blower Package/mm	1060970580
Standard Parts	Main Body,Bottom stand,Remote control, Foot switch,2 UV lamps and Fluorescent Lamp,exhaust duct, exhaust blower,sockets
Option Items	Armrest, Air curtain tester, Formalin fumigation sterilizer,Ammonium hydrogen carbonate neutralizer,infrared sterilizer
