| Prod Model: |
MT2200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Length: |
2100± 50mm; |
| Width: |
500± 20mm; |
| Height: |
(740-1100)± 50mm |
| Forward: |
25 Degree; |
| Backward: |
25degree; |
| Material: |
Metal |
| Type: |
Medical Table |
Product Description
Length: 2000± 50mm;
Width: 500± 20mm;
Height: (740-1100)± 50mm
Forward: ≥ 25°
Backward: ≥ 25°
Leftward, Rightward: ≥ 15°
Head board fold upward: ≥ 25°
Head board fold downward: ≥ 25°
Seat board fold upward: ≥ 70°
Seat board fold downward: ≥ 45°
Leg board fold upward: ≥ 15°
Leg board fold downward: ≥ 60°
Foot board fold downward: ≥ 75°
Foot board furcation include angle: 180°
Mains voltage: AC 220V 50Hz
Accumulator Cell: 12V 12Ah
Input power: 500VA
Features:1. It adopts hydraulic engine imported from Germany as the driving force.
Electrical operation bed has a top-panel composed of five movable boards including head board, back board, hip board, thigh board and crus board. This top-panel supports 6 kinds of body positions by electric hydraulic control which controls up and down, forward and backward tilts and leftward and rightward tilts of the top panel, the upward and downward folding of the hip board, the upward and downward folding of the leg boards, and the locking and unlocking of the base. The changes of the angles of the head board and crus board are adjusted manually through pneumatic spring.
2. It has hand-control and panel-control which work respectively, adopts MCU process, and its self-lock can avoid error-touch.
Electrical operation bed can control various body positions through two kinds of control panels, i. e., one handy controller and one supplementary control panel. When the handy controller fails, the supplementary controller may be used to control the bed.
3. Its engine uses DC24V, which increases the security of electric. AC and DC can use at the same time.
4. It can do the C-arm, X-ray examination.
This bed adopts the eccentric column design. Also the head part and the leg part of the table can exchange. So it realizes the C-arm X-ray machines photograph of the whole ranges of body positions. It also supports the X-ray photograph by a cassette.
5. It has the function of auto-restoration, and adopts Germany CONTELEC sensor.
This operation bed has a Convex Top-panel key and a Concave Top-panel key to provide convenience to the operations on gallbladder or kidney. This bed has a HorizontalnessReset key to reset the whole top panel of the bed to the horizontal position.
6. It is all made of high-quality stainless steel.
