| Prod Model: |
BAE314 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Three Independent Motors: |
Yes |
| Nurse Controller: |
Yes |
| Patient Touching Surface: |
1960*900mm |
| Siderails Up: |
1050mm |
| Siderail Down: |
990mm |
| Weight&Nbsp;Load: |
250kg |
| Backrest&Nbsp;Max&Nbsp;Upward&Nbsp;Angle: |
75° |
| Footrest&Nbsp;Max&Nbsp;Upward&Nbsp;Angle: |
&Nbsp;40° |
| Power: |
220VAC or 110VAC |
| Frequency: |
50-60Hz |
| Material: |
Metal |
| Type Of Hospital Bed: |
Electric Bed |
| Folded: |
Unfolded |
| Using Ambient: |
Hospital |
| Numbers Of Function: |
Three-function |
| Certification: |
ISO13485 |
Product Description
BAE314 Full Electric Three Function Medical Hospital Motor Bed with Nurse Controller on Foot End
General Description:
This WANROOEMED BAE314 Full Electric Three Motor medical bed consist of 3 motors, and 4 pcs of PP siderails. The advantage is with nurse controller on foot end, easy for nurse to control the bed position.
Feature:
- Nurse controller on foot end
- Made of superior cold-rolled steel
- One step forming sleeping bed, with soft connection
- Treated by shot blasting, electrophoresis and powder coating
- Four pieces of PP complete side rails, full protection with zero gap, tuck-away
- Central braking system-5 inch diameter castor
- Three independent motors
-IV stand holder, Urine hook, IV pole
-auto contour feature simultaneously raises both the head and the knees-optional
Standard Specifications:| Model number | BAE314 |
| | |
| Measurement | Overall size(L*W*H): 2160*1050*450-700mm(with 5 inch diameter castor)
Patient Touching surface: 1960*900mm
Siderails up: 1050mm
Siderail down:990mm |
| Weight Load | Fully tested sturdy construction capable of taking a maximum user weight of up to
250kg |
| Function | Backrest max upward angle: 75° |
| Footrest max upward angle: 40° |
| Height:450-700mm(castor diameter: 5 inch) |
| Power | 220VAC or 110VAC Frequency: 50-60HZ
Power Plug: EU type standard if other type, confirm each order |
Standard Accessories List:| Headboard/Footboard | 1 set |
| Siderails | 4 pcs |
| I.V pole | 1 piece |
| Castor | 4 pieces/5 inch |
| Drainage Hook | 2 pieces |
| Motor | 3 pcs |
Optional:
