HUANGSHI TAIDONG MATERIAL TECHNOLOGY CO., LTD. >> Factory Supply 1.2312/P20+S Plastic Mould Steel, Flat Steel Round Bar
Factory Supply 1.2312/P20+S Plastic Mould Steel, Flat Steel Round Bar
| Price: | US $ 800-1500/Ton |
|---|---|
| Min Order: | 2/Ton |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
Good quality with DIN1.2312/P20+S Plastic mould steel, steel plate:
1.2312 P20+S tool steel round bar for plastic mold
Product Description:
1. AISI P20, JIS SKT3, 5CrMnMo Hot work tool steel
2. Hot rolled or Forged, condition annealing, black surface
3. Hardness: ≤ 255HBS;
4. Hot rolled technology: EAF+LF+VD
5. Ultrasonic test standard: SPE1921-GR3, CLASS D/D or E/E
Applications:
1. Diecasting mould(mold, fixed block, upper die, jet nozzle, nitride thimble ).
2. Extrusion die(mold, supporting member, choke blocks).
3. Hot press die. (aluminum, magnesium, copper alloy)
4. Parts, such as cold cutting, overlap, hot shears, wearable parts.
5. Important parts for aviation industry.
1.2312 P20+S tool steel round bar for plastic mold
Product Description:
1. AISI P20, JIS SKT3, 5CrMnMo Hot work tool steel
2. Hot rolled or Forged, condition annealing, black surface
3. Hardness: ≤ 255HBS;
4. Hot rolled technology: EAF+LF+VD
5. Ultrasonic test standard: SPE1921-GR3, CLASS D/D or E/E
| Standard | Grade | Chemical composition (%) | |||||||||
| C | Si | Mn | Cr | Mo | V | Ni | W | Cu | Ti | ||
| GB | 5CrMnMo | 0.32-0.42 | 0.80-1.20 | 0.20-0.50 | 4.75-5.50 | 1.10-1.75 | -- | -- | -- | -- | -- |
| AISI | P20 | 0.30-0.40 | 0.80-1.20 | 0.20-0.40 | 4.75-5.50 | 1.25-1.75 | -- | -- | -- | -- | -- |
| JIS | SKT3 | 0.35-0.42 | 0.80-1.20 | 0.25-0.50 | 4.80-5.50 | 1.00-1.50 | -- | -- | -- | -- | -- |
| DIN | -- | 0.37-0.42 | 0.90-1.20 | 0.30-0.50 | 4.80-5.50 | 1.20-1.50 | -- | -- | -- | ||
| Size of P20/1.2311 Hot Work Mould Steel | |||
| Round bar | Diameter(mm) | Length (mm) | |
| Max:800 | Max: 9000 | ||
| Plate | Thickness(mm) | Width (mm) | Length (mm) |
| Max:800 | Max:1000 | Max:6500 | |
Applications:
1. Diecasting mould(mold, fixed block, upper die, jet nozzle, nitride thimble ).
2. Extrusion die(mold, supporting member, choke blocks).
3. Hot press die. (aluminum, magnesium, copper alloy)
4. Parts, such as cold cutting, overlap, hot shears, wearable parts.
5. Important parts for aviation industry.
| Prod Model: | 1.2312/P20+S |
|---|---|
| Deliver Time: | 20-50 Days |
| Payment Terms: | T/T.L/C&D/P at Sight |
| Delivery Terms: | Fob, CFR, CIF |
| Stock Supply: | Within 3-7 Days |
| Mass Production: | Within 20-50 Days |
| Service Supply: | Samples&Chemicial Components After Order |
| Type: | Special Steel Bar |
| Standard: | BS |
| Special Use: | Good Tenacity |
| Application: | Tool Steel Bar |
| Composition: | Alloy Steel Scrap |
| Technique: | Forged, Hot Rolled |
| Shape: | Flat, Bar |
| Surface Treatment: | Black Surface, Peeled, Machined or Turned, Grinded |
