Good Quality with DIN1.2312/P20+S Plastic Mould Steel, Steel Plate

Good Quality with DIN1.2312/P20+S Plastic Mould Steel, Steel Plate
Price: US $ 800-1500/Ton
Min Order: 2/Ton
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: DIN1.2312/P20+S
Deliver Time: 20-50 Days
Payment Terms: T/T.L/C&D/P at Sight
Delivery Terms: Fob, CFR, CIF
Stock Supply: Within 3-7 Days
Mass Production: Within 20-50 Days
Service Supply: Samples&Chemicial Components After Order
Type: Special Steel Bar
Standard: BS
Special Use: Good Tenacity
Application: Tool Steel Bar
Composition: Alloy Steel Scrap
Technique: Forged, Hot Rolled
Shape: Flat, Bar
Surface Treatment: Black Surface, Peeled, Machined or Turned, Grinded

Product Description

Good quality with DIN1.2312/P20+S Plastic mould steel, steel plate:

1.2312 P20+S tool steel round bar for plastic mold
Product Description:
1. AISI P20, JIS SKT3, 5CrMnMo Hot work tool steel
2. Hot rolled or Forged, condition annealing, black surface
3. Hardness: ≤ 255HBS;
4. Hot rolled technology: EAF+LF+VD
5. Ultrasonic test standard: SPE1921-GR3, CLASS D/D or E/E
StandardGradeChemical composition (%)
  CSiMnCrMoVNiWCuTi
GB5CrMnMo0.32-0.420.80-1.200.20-0.504.75-5.501.10-1.75----------
AISIP200.30-0.400.80-1.200.20-0.404.75-5.501.25-1.75----------
JISSKT30.35-0.420.80-1.200.25-0.504.80-5.501.00-1.50----------
DIN--0.37-0.420.90-1.200.30-0.504.80-5.501.20-1.50------
Size of P20/1.2311 Hot Work Mould Steel
Round barDiameter(mm)Length (mm)
Max:800Max: 9000
PlateThickness(mm)Width (mm)Length (mm)
Max:800Max:1000Max:6500

Applications:
1. Diecasting mould(mold, fixed block, upper die, jet nozzle, nitride thimble ).
2. Extrusion die(mold, supporting member,  choke blocks).
3. Hot press die. (aluminum, magnesium, copper alloy)
4. Parts, such as cold cutting, overlap, hot shears, wearable parts.
5. Important parts for aviation industry.









Huangshi Taidong Material Technology Co., Ltd, which bases on Daye Jingcheng Mould Co., Ltd, is the leading supplier and professional manufacturer of steel. Our company is located in Huangshi city which is the tool steel production centre of China. Our company is mainly specialized in producing various steels, including cold work tool steel, hot work tool steel, plastic mould steel, high speed tool steel, carbon steel, bearing steel, and all kinds of alloy steel, etc.

As an integrated manufacturing and trade enterprise, we not only supply the high quality steel, but also offer the flexible and appropriate steel solutions by our competent technical team and customer service team. Customized material and service make our business to be a distinct one.

In Taidong, every detail is well-controlled, every requirement is responded honestly, every promise is fulfilled exactly. In Taidong, we may not supply the world best steel, but can promise the most honest reply for your every question, and the most loyal implementation of our order.

We look forward to meeting your challenges.
