Paperboard Bursting Strength Test Equipment for Paperboard/Cloth/ Leather/Fabric
| Price: | US $ 2000-3000/Piece |
|---|---|
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Western Union,Paypal |
Paperboard Bursting Strength Test Equipment for paperboard/cloth/ leather/Fabric
1. One year free after-sale service
2. High quality with reasonable price
Model: XB-OTS-209B
Introductions:
Bursting strength tester for packaging industry is fit for products which are packaged by corrugated paper such as electronic instruments, electric ware, hardwares, bike, valise, food, shoe, furniture etc,to test the bursting-resistance strength of paper box; it can also test cloth and synthetic leather.
This type of bursting strength tester is adapted with signal output of pressure. While specimen is breaking, the max. breaking value will be kept with the alarm buzzer & alert light automatically. Its Accuracy has promoted 20 times more than the traditional gauge.
Features of Paperboard Bursting Strength Testing Machine
1. It is applicable to test bursting strength for paperboard.
2. Advanced micro computer controller and digital processor ensure result precise.
3. Printer facility and fully detailed test reports.
4. Results of the tests are stored for viewing or for printing out as required.
5. User-friendly menu interface.
6. Power protection ensure automatic record when power cut off.
Design standards:
JIS-L1004,L1018,L1031,K6328,P8131,P8112 ASTM-D2210,TAPPI T403,ISO2759-2001,GB/T1539
Technical Parameters:
Packing & Shipping
1.Strong standard wood case, inner plastic films wrapped for Bursting Strength Testing Machine
2.Usually we delivery the equipment by air,by sea or by express. it depends on customer
Our Main Products
Enviromental reliability Testing Series:
Temperature humidity cycling Test Chambers..
Environmental /Climatic test chambers...
High Low Temperature Chambers...
More...
Physical Testing Equipment Series:
Floor testing machine...
Tensile Strength Testing Machines...
Shaker/Vibration Test Machine...
Our Services
We are here to help you. Services available:
Replacement manuals
Consumables and replacement parts
On-site maintenance and repair
Warranty support
Over-the-phone service support and advice
If you have an OTS chamber, we will do our best to help you in whatever way we can.
Manuals: PDF files of manuals for current models are available free. Please contact us to request a copy. Older and printed copies at additional charge.
Service repair: We prefer you contact us direct at the factory with any problems you may be experiencing. We help diagnose the problem, arrange for any needed parts, and schedule a technician to do the repairs. Rarely can a local contractor get all that done for you as quickly as we can. We also guarantee the work.
RFQ
Q1 : Can you customize the product?
A: Yes, we can customize any products according to requirements.
Q2 : How to choose the most suitable products?
A: Our professional team will give you the best suggestion,just be patiently to tell us the information about the parameters your required.
Q3 : Can you arrange installations and commissioning in our lab?
A: Firstly, for standard chamber we had 3-5 days commissioning before shipping , you just need link power in your lab, then can start to operate. Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it. Thirdly, some of customized chambers we should to install and teach your team to operate .
For More Information .....
Please do not hesitate to contact us!!!
Or Send your inquiry below...
1. One year free after-sale service
2. High quality with reasonable price
Model: XB-OTS-209B
Introductions:
Bursting strength tester for packaging industry is fit for products which are packaged by corrugated paper such as electronic instruments, electric ware, hardwares, bike, valise, food, shoe, furniture etc,to test the bursting-resistance strength of paper box; it can also test cloth and synthetic leather.
This type of bursting strength tester is adapted with signal output of pressure. While specimen is breaking, the max. breaking value will be kept with the alarm buzzer & alert light automatically. Its Accuracy has promoted 20 times more than the traditional gauge.
Features of Paperboard Bursting Strength Testing Machine
1. It is applicable to test bursting strength for paperboard.
2. Advanced micro computer controller and digital processor ensure result precise.
3. Printer facility and fully detailed test reports.
4. Results of the tests are stored for viewing or for printing out as required.
5. User-friendly menu interface.
6. Power protection ensure automatic record when power cut off.
Design standards:
JIS-L1004,L1018,L1031,K6328,P8131,P8112 ASTM-D2210,TAPPI T403,ISO2759-2001,GB/T1539
Technical Parameters:
| Model | XB-OTS-209B |
| Capacity (Optional) | High Pressure 0~100 Kg/ cm^2 (0.1kg/cm^2) |
| Unit (sitchable) | Kpa, psi, kg/cm^2 |
| Accuracy | ± 0.5% |
| Pressure Range | 250~5600kpa |
| Speed of Compression | High Pressure 170 ±10ml/min |
| Specimen Clamping Force | >690kpa |
| Oil | 100% silicon oil |
| Sensing method | Pressure Transmitter |
| Indicating Method | Digital |
| Display | LCD |
| Material of the Ring | Stainless Steel SUS304 |
| Opening in Upper Clamp | 31.5 ± 0.05 mm Diameter |
| Opening in Lower Clamp | 31.5 ± 0.05 mm Diameter |
| Motor | Anti-vibration Motor 1/4 HP |
| Operation Method | Semi-automatic |
| Dimension (L*W*H) | 430*530*520 mm |
| Weight | Approx. 64 kg |
| Power | 1 , AC220± 10%, 50 Hz |
| Power Capacity | 120W |
| Standard Configuration | Rubber Membrane 1 piece, Spanner 1 set, Correction Shim 10 sheets, Glycerin 1 bottle |
| Optional Configuration | Printer |
| Standard | JIS-L1004, L1018, L1031, K6328, P8131, P8112 ASTM-D2210; TAPPIT403TS-63 ISO2759-2001; GB/T1539 |
Packing & Shipping
1.Strong standard wood case, inner plastic films wrapped for Bursting Strength Testing Machine
2.Usually we delivery the equipment by air,by sea or by express. it depends on customer
Our Main Products
Enviromental reliability Testing Series:
Temperature humidity cycling Test Chambers..
Environmental /Climatic test chambers...
High Low Temperature Chambers...
More...
Physical Testing Equipment Series:
Floor testing machine...
Tensile Strength Testing Machines...
Shaker/Vibration Test Machine...
Our Services
We are here to help you. Services available:
Replacement manuals
Consumables and replacement parts
On-site maintenance and repair
Warranty support
Over-the-phone service support and advice
If you have an OTS chamber, we will do our best to help you in whatever way we can.
Manuals: PDF files of manuals for current models are available free. Please contact us to request a copy. Older and printed copies at additional charge.
Service repair: We prefer you contact us direct at the factory with any problems you may be experiencing. We help diagnose the problem, arrange for any needed parts, and schedule a technician to do the repairs. Rarely can a local contractor get all that done for you as quickly as we can. We also guarantee the work.
RFQ
Q1 : Can you customize the product?
A: Yes, we can customize any products according to requirements.
Q2 : How to choose the most suitable products?
A: Our professional team will give you the best suggestion,just be patiently to tell us the information about the parameters your required.
Q3 : Can you arrange installations and commissioning in our lab?
A: Firstly, for standard chamber we had 3-5 days commissioning before shipping , you just need link power in your lab, then can start to operate. Secondly; we had detailed operation manual with chamber , any problems you can find and solve in it. Thirdly, some of customized chambers we should to install and teach your team to operate .
For More Information .....
Please do not hesitate to contact us!!!
Or Send your inquiry below...
| Prod Model: | XB-OTS-209B |
|---|---|
| Capacity (Optional): | High Pressure 0~100 Kg/ Cm^2(0.1kg/Cm^2) |
| Standards: | JIS-L1004, ASTM-D2210, Tappi T403, ISO2759-2001 |
| Accuracy: | < 0.5% |
| Pressure Range: | 250~5600kpa |
| Oil: | 100% Silicon Oil |
| Dimension (L*W*H): | 430*530*520 mm |
| Material Of The Ring: | Stainless Steel SUS304 |
| Sensing Method: | Pressure Transmitter |
| Speed Of Compression: | High Pressure 170+- 10ml/Min |
| Motor: | Anti-Vibration Motor 1/4 HP |
| Type: | Strength Testing Machine |
| Weight: | 0-100Kg |
| Power Source: | AC220V |
